| 型号 | 名义制冷量KW | 电加 热量 | 额定 风量KW | 电极加 湿器KG | 加湿器 功率KW | 机外余 压Pa | 机组噪音 dB(A) | 制冷剂 (类型) | 室内机组外形尺寸MM | 室内机组重量KG | 电源 | 进/排水管径mm | 冷凝风量m3/H | 室外冷凝机组外形尺寸MM | 风冷冷凝机组 重量KG | 机组电源配线 总容量KW |
| SDHF-5Q | 5.2 | 3 | 1000 | 2 | 1.5 | 80 | 65 | R22 | 620*580*150 | 120 | 220V/50Hz | 20 | 2000 | 950*400*835 | 60 | 5.25 |
| SDHF-7Q | 8.2 | 5 | 1500 | 4 | 3 | 80 | 62 | R22 | 800*580*1900 | 160 | 380V/50Hz | 20 | 4000 | 735*635*795 | 75 | 11.1 |
| SDHF-9Q | 8.5 | 6 | 2300 | 4 | 3 | 80 | 62 | R22 | 800*580*1900 | 180 | 220V/50Hz | 20 | 5500 | 735*635*795 | 75 | 12.8 |
| SDHF-12Q | 12 | 8 | 3000 | 5 | 3.75 | 90 | 67 | R22 | 850*580*1900 | 200 | 380V/50Hz | 20 | 6800 | 835*740*950 | 85 | 16.9 |
| SDHF-15Q | 15 | 9 | 3200 | 5 | 3.75 | 90 | 67 | R22 | 850*580*1900 | 200 | 380V/50Hz | 20 | 6800 | 835*740*950 | 85 | 16.9 |
| SDHF-20Q | 19.5 | 9 | 4300 | 6 | 4.5 | 90 | 67 | R22 | 1195*580*1900 | 240 | 380V/50Hz | 20/25 | 8000 | 785*785*1155 | 120 | 20 |
| SDHF-25Q | 25.5 | 16 | 5000 | 8 | 6 | 100 | 69 | R22 | 1300*740*2050 | 300 | 380V/50Hz | 20/25 | 10500 | 955*820*1155 | 140 | 26.05 |
| SDHF-30Q | 30 | 18 | 6200 | 9 | 6.5 | 150 | 69 | R22 | 1300*740*2050 | 300 | 380V/50Hz | 20/25 | 6800*2 | 835*740*950 | 85 | 31 |
| SDHF-36Q | 36 | 21 | 7200 | 10 | 7.5 | 150 | 70 | R22 | 1550*740*2250 | 350 | 380V/50Hz | 20/25 | 8000*2 | 885*785*1155 | 120*2 | 41.4 |
| SDHF-40Q | 40 | 25 | 8000 | 10 | 7.5 | 200 | 70 | R22 | 1550*740*2250 | 350 | 380V/50Hz | 20/25 | 8000*2 | 885*785*1155 | 120*2 | 41.4 |
| SDHF-45Q | 45 | 30 | 9000 | 12 | 9 | 200 | 70 | R22 | 1550*740*2250 | 350 | 380V/50Hz | 20/25 | 8000*2 | 885*785*1155 | 120*2 | 41.4 |
| SDHF-50Q | 49 | 27 | 10000 | 12 | 9 | 200 | 70 | R22 | 1650*740*2250 | 400 | 380V/50Hz | 20/25 | 10500*2 | 955*820*1155 | 140*2 | 51.4 |
| SDHF-60Q | 60 | 36 | 12000 | 10 | 7.5 | 300 | 72 | R22 | 1850*1050*2350 | 500 | 380V/50Hz | 20/25 | 17000*2 | 955*860*1255 | 170*2 | 66 |
